Soyuz TM-9

---

Mir EVA - Get a Grip Credit: RKK Energia

AKA: Mir EO-6;Rodnik (Spring - water spring). Launched: 1990-02-11. Returned: 1990-08-09. Number crew: 2 . Duration: 179.05 days.

The crew also conducted an extensive program of geophysical and astrophysical research, experiments on biology and biotechnology and work on space materials science. They landed safely on August 9, 1990 07:35 GMT, 70 km from Arkalyk at 50 deg 51'E 67 deg 17' N.

Narrative (adapted from D S F Portree's Mir Hardware Heritage, NASA RP-1357, 1995)

On February 13 the EO-6 relief crew of Balandin and Solovyov arrived at the station aboard Soyuz TM-9. Soon after they arrived in orbit, Balandin and Solovyov noted that three of eight thermal insulation blankets on their spacecraft's descent module had come loose at their lower (heat shield) ends and were waving about as the spacecraft maneuvered in space. It was thought they could block optical navigation sensors, and that the damaged insulation might cause the spacecraft to overheat or cool down so much that condensation would form on its optical equipment. The possibility existed that an electrical short might occur if condensation developed on equipment. Docking with Mir occurred as normal. The cosmonauts and TsUP worked out procedures by which the TsUP monitored Soyuz TM-9's temperature and maneuvered Mir to move it in and out of sunlight as needed to maintain proper temperature. In the meantime, cosmonauts worked in the hydrolab training facility in Zvezdny Gorodok, outside Moscow, to develop EVA repair procedures. Consideration was also given to sending a rescue Soyuz-TM carrying a single cosmonaut to pick up the cosmonauts and return them to Earth.

The problem was considered manageable and the Soyuz TM-8 crew had an uneventful return to earth on 19 February after a productive mission.

Progress M-3 arrived and remained docked with the station from March 3-April 27, 1990. It delivered replacement parts for Mir, including new storage batteries, electrical system components, and computer parts. The cosmonauts began installing these by March 7. Most of March was taken up with work on the computer system.

When Soyuz-TM 9 was launched, the Soviets stated that Kristall would launch on March 30 and dock April 7. On April 20 the Soviets announced that the Kristall module would not be launched until June 1. The cause of the delay was continued work to turn over control of the Mir complex to the new Salyut 5B computer. Difficulty had also been experienced in integrating Kvant 2's gyrodynes into the Mir attitude control system.

From May 7-27, 1990 Progress 42 occupied the aft port of Mir. This was the last of the highly successful series of Progress vehicles. It marked the 43rd Progress docking (counting Cosmos 1669), all of which were successful. The Progress freighters delivered 99 tons of material to Salyut 6, Salyut 7, and Mir. Use of Progress 42 forced a delay in the integration of the Salyut 5B control computer delivered with Kvant 2, as Progress 42 could interface only with the old Argon 16B system.

The long-awaited, much-delayed Kristall module arrived at Mir's front port on June 10, and was relocated to the lateral port opposite Kvant 2 on June 11. This restored the equilibrium of the complex, which had been asymmetrical since Kvant 2 was placed at a lateral port in December 1989. The module was launched May 31. It had aborted its first docking attempt on June 6 due to an attitude control thruster failure. Delays in launch and docking affected Balandin and Solovyov, who were scheduled to return to Earth at the end of July. Their mission was extended 10 days to permit them to activate Kristall's systems, and to accommodate the EVA to repair the loose thermal blankets on Soyuz-TM 9.

Solovyov and Balandin had not previously been trained to perform an EVA. They trained by videotape sent up from the ground on a Progress spacecraft, and also by observing practice sessions televised from the hydrobasin. Special EVA tools were manufactured and sent to the cosmonauts. On July 3 they moved Soyuz-TM 9 to the Mir front port so it could be more easily reached for repairs.

On July 17 they opened the Kvant 2 EVA hatch before the airlock was completely evacuated of air. The hatch slammed back on its hinges. They used a pair of clamps, which they attached to handholds, to move down Kvant 2. They also secured themselves with long and short ropes. After 1.5 hr they reached the multiport docking node. They attached to Kvant 2 ladders for reaching the damage site on their Soyuz-TM. The cosmonauts determined that the Soyuz-TM 9 descent module remained in excellent condition. However, the thermal blankets had shrunk, making them impossible to reattach. They fell back on a contingency plan by folding two of the three blankets in half.

They were well behind schedule by this point. They left their tools and ladders at the repair site and hurried to return to Mir, as the rated endurance of their suits (6.5 hr) had been exceeded. This meant crawling over Kvant 2's hull in the dark. They found that the Kvant 2 hatch would not close. To permit them to re-enter the pressurized portion of Mir, the central compartment of Kvant 2 was called into play as an emergency airlock, as it had been designed to do. The EVA lasted 7 hr, 16 min.

Solovyov and Balandin depressurized the Kvant 2 central compartment on July 25. After several attempts to close the outside hatch from inside, they televised images of the damaged hinge to the TsUP, then returned to the multiport node to secure their ladders. Finally, they removed a portion of the hinge cover, which had broken and become lodged between the hatch and its frame. They found the hatch much easier to close and seal after this. They repressurised the EVA airlock. The EVA lasted 3 hr, 31 min.

The EO-7 relief crew arrived aboard Soyuz TM-10 on August 3. The new crew arrived at Mir's aft port with four passengers -- quail for cages in Kvant 2. A quail laid an egg en route to the station. It was returned to Earth, along with 130 kg of experiment results and industrial products, in Soyuz TM-9. The spacecraft landed without incident.

Photo Gallery

---

---

Soyuz TM-9 Loose thermal blankets on Soyuz TM-9. Credit: RKK Energia

---

---

Soyuz TM-9 Baladin and Solovyov aboard Mir. Credit: RKK Energia

---

• Soyuz TM-9 - . Call Sign: Rodnik (Spring - water spring). Crew: Balandin, Solovyov. Backup Crew: Manakov, Strekalov. Payload: Soyuz TM s/n 60. Mass: 7,150 kg (15,760 lb). Nation: Russia. Agency: MOM. Program: Mir. Class: Manned. Type: Manned spacecraft. Flight: Soyuz TM-8, Soyuz TM-9. Spacecraft Bus: Soyuz. Spacecraft: Soyuz TM. Duration: 179.05 days. Decay Date: 1990-08-09 . USAF Sat Cat: 20494 . COSPAR: 1990-014A. Apogee: 387 km (240 mi). Perigee: 373 km (231 mi). Inclination: 51.60 deg. Period: 92.20 min.

  Manned two crew. Mir Expedition EO-06. Docked with Mir. Transported to the Mir orbital station a crew comprising the cosmonauts A Y Solovyov and A N Balandin to conduct an extensive programme of geophysical and astrophysical research, experiments on biology and biotechnology and work on space materials science.

• Landing of Soyuz TM-8 - . Return Crew: Serebrov, Viktorenko. Nation: Russia. Related Persons: Serebrov, Viktorenko. Program: Mir. Flight: Soyuz TM-8, Soyuz TM-9. Soyuz TM-8 landed at 04:36 GMT. .

• Progress M-3 - . Payload: Progress M s/n 203. Mass: 7,249 kg (15,981 lb). Nation: Russia. Agency: MOM. Program: Mir. Class: Manned. Type: Manned logistics spacecraft. Flight: Soyuz TM-9. Spacecraft Bus: Soyuz. Spacecraft: Progress M. Duration: 58.07 days. Completed Operations Date: 1990-04-29 00:52:03 . Decay Date: 1990-04-29 00:52:03 . USAF Sat Cat: 20513 . COSPAR: 1990-020A. Apogee: 218 km (135 mi). Perigee: 183 km (113 mi). Inclination: 51.60 deg. Period: 88.50 min. Unmanned resupply vessel to Mir. Docked with Mir on 3 Mar 1990 01:04:32 GMT. Undocked on 27 Apr 1990 20:24:43 GMT. Destroyed in reentry on 28 Apr 1990 00:52:00 GMT. Total free-flight time 2.26 days. Total docked time 55.81 days..

• Progress 42 - . Payload: Progress s/n 150. Mass: 7,011 kg (15,456 lb). Nation: Russia. Agency: MOM. Program: Mir. Class: Manned. Type: Manned logistics spacecraft. Flight: Soyuz TM-9. Spacecraft Bus: Soyuz. Spacecraft: Progress. Duration: 21.66 days. Completed Operations Date: 1990-05-28 12:27:29 . Decay Date: 1990-05-28 12:27:29 . USAF Sat Cat: 20602 . COSPAR: 1990-041A. Apogee: 243 km (150 mi). Perigee: 188 km (116 mi). Inclination: 51.60 deg. Period: 88.80 min.

  Unmanned resupply vessel to Mir; last of original design Progress spacecraft. Conducted fifth and final test of Buran ejection seat during ascent to orbit. The K-36M.11F35 seat was installed in an 'experimental droppable compartment' installed in place of the Launch Escape Tower engine on top of the shroud. Docked with Mir on 7 May 1990 22:45:03 GMT. Undocked on 27 May 1990 07:08:58 GMT. Destroyed in reentry on 27 May 1990 12:27:30 GMT. Total free-flight time 2.31 days. Total docked time 19.35 days.

• Kristall - . Payload: 77KST s/n 17201. Mass: 19,640 kg (43,290 lb). Nation: Russia. Agency: MOM. Program: Mir. Class: Manned. Type: Manned space station. Flight: Soyuz TM-9. Spacecraft Bus: Mir. Spacecraft: Kristall. Decay Date: 2001-03-23 . USAF Sat Cat: 20635 . COSPAR: 1990-048A. Apogee: 397 km (246 mi). Perigee: 388 km (241 mi). Inclination: 51.60 deg. Period: 92.40 min.

  Mir module; materials processing laboratory. Docked with Mir. Kristall: Mass: 19,500 kg. Mass on docking 17,200 kg. Length: 11. 9 m or 13. 73 m?. Solar array span 36 m. Diameter: 4. 35 m. Payload: 7,000 kg. Two compartments. Instrument-Payload Compartment contains food containers, and industrial processing units Krater 3, Optizon 1, Zona 02, and Zona 03. 0. 8 m hatch leads to Junction-Docking compartment. This contains spherical universal docker with two APAS-89 androgynous docking units. These will be used to dock with Buran shuttle and 1,000 kg X-ray telescope to be delivered by Buran in 1991. Third opening houses earth observation cameras.
  Launch originally planned for 30 March 1990. Delayed to April 18, then further delayed due to computer chip problems.
  Launched 31 May 1990 12:33 GMT. Docking scheduled June 6 at 12:36 but delayed due to problem with one of Kristall's orientation engines. Docking successful 10 June at 12:47. On June 11 moved to side port. Work within module began 15 June.
  Spektr: Late 1991 launch. Remote sensing work. Occupies port opposite Kvant 2. Before this occurs Kristall solar arrays will be relocated to Kvant.
  Officially: Specialized module. Experimental-industrial production of semi-conducting materials; refinement of biologically active substances for the production of new medicinal preparations. Cultivation of crystals of different albumine compositions and hybridizatio n of cells. Conduct of astrophysical and technical experiments.

• EVA Mir EO-6-1 - . Crew: Balandin, Solovyov. EVA Duration: 0.30 days. Nation: Russia. Related Persons: Balandin, Solovyov. Program: Mir. Class: Manned. Type: Manned space station. Flight: Soyuz TM-9. Spacecraft: Mir. Repaired Soyuz TM-9 insulation rip..

• EVA Mir EO-6-2 - . Crew: Balandin, Solovyov. EVA Duration: 0.15 days. Nation: Russia. Related Persons: Balandin, Solovyov. Program: Mir. Class: Manned. Type: Manned space station. Flight: Soyuz TM-9. Spacecraft: Mir. Dismantled equipment. Temporarily closed damaged hatch..

• Soyuz TM-10 - . Call Sign: Vulkan (Volcano ). Crew: Manakov, Strekalov. Backup Crew: Afanasyev, Manarov. Payload: Soyuz TM s/n 61A. Mass: 7,150 kg (15,760 lb). Nation: Russia. Agency: MOM. Program: Mir. Class: Manned. Type: Manned spacecraft. Flight: Soyuz TM-10, Soyuz TM-9. Spacecraft Bus: Soyuz. Spacecraft: Soyuz TM. Duration: 130.86 days. Decay Date: 1990-12-10 . USAF Sat Cat: 20722 . COSPAR: 1990-067A. Apogee: 219 km (136 mi). Perigee: 198 km (123 mi). Inclination: 51.60 deg. Period: 88.70 min.

  Manned two crew. Docked with Mir. Mir Expedition EO-07. Transported to the Mir manned orbital station the crew consisting of the cosmonauts G M Manakov and G M Strekalov for the purpose of carrying out a programme of geophysical and astrophysical research, biological and biotechnological experiments, and work on space-materials science.

• Landing of Soyuz TM-9 - . Return Crew: Balandin, Solovyov. Nation: Russia. Related Persons: Balandin, Solovyov. Program: Mir. Flight: Soyuz TM-10, Soyuz TM-9. Soyuz TM-9 landed at 07:35 GMT, 70 km from Arkalyk at 50 deg 51'E 67 deg 17' N..
