Chang Zheng 2F
Part of CZ Family
CZ-2F on pad
CZ-2F on pad
Chinese orbital launch vehicle. Man-rated version of CZ-2E, designed for launch of the Shenzhou spacecraft. Little difference externally. Modifications were related to improved redundancy of systems, strengthened upper stage to handle large 921-1 spacecraft fairing and launch escape tower. President Jiang Zemin gave the name 'Shenjian' ('Divine Arrow') to the CZ-2F after the successful launch of the Shenzhou-3 mission.

AKA: Chang Zheng-2F; CZ-2F; Divine Arrow; Long March 2F; Shenjian. Status: Active. First Launch: 1999-11-19. Last Launch: 2013-06-11. Number: 10 . Payload: 8,400 kg (18,500 lb). Thrust: 5,920.00 kN (1,330,860 lbf). Gross mass: 464,000 kg (1,022,000 lb). Height: 62.00 m (203.00 ft). Diameter: 3.35 m (10.99 ft). Apogee: 185 km (114 mi).

LEO Payload: 8,400 kg (18,500 lb) to a 185 km orbit at 57.00 degrees. Payload: 3,500 kg (7,700 lb) to a GTO.

Stage Data - CZ-2F

  • Stage 0. 4 x CZ-2E-0. Gross Mass: 41,000 kg (90,000 lb). Empty Mass: 3,200 kg (7,000 lb). Thrust (vac): 816.285 kN (183,508 lbf). Isp: 291 sec. Burn time: 128 sec. Isp(sl): 261 sec. Diameter: 2.25 m (7.38 ft). Span: 2.26 m (7.41 ft). Length: 15.33 m (50.29 ft). Propellants: N2O4/UDMH. No Engines: 1. Engine: YF-20B. Other designations: LB-40. Status: In Production.
  • Stage 1. 1 x CZ-2E-1. Gross Mass: 196,500 kg (433,200 lb). Empty Mass: 9,500 kg (20,900 lb). Thrust (vac): 3,265.143 kN (734,033 lbf). Isp: 289 sec. Burn time: 166 sec. Isp(sl): 261 sec. Diameter: 3.35 m (10.99 ft). Span: 6.00 m (19.60 ft). Length: 23.70 m (77.70 ft). Propellants: N2O4/UDMH. No Engines: 4. Engine: YF-20B. Other designations: L-180. Status: In Production.
  • Stage 2. 1 x CZ-2E-2. Gross Mass: 91,500 kg (201,700 lb). Empty Mass: 5,500 kg (12,100 lb). Thrust (vac): 831.005 kN (186,817 lbf). Isp: 298 sec. Burn time: 295 sec. Isp(sl): 260 sec. Diameter: 3.35 m (10.99 ft). Span: 3.35 m (10.99 ft). Length: 15.52 m (50.91 ft). Propellants: N2O4/UDMH. No Engines: 1. Engine: YF-25/23. Other designations: L-90. Status: In Production.

Family: orbital launch vehicle. Country: China. Spacecraft: Shenzhou, Shenzhou OM, Ban Xing, Tiangong. Launch Sites: Jiuquan, Jiuquan SLS. Stages: CZ-2E-1, CZ-2E-2, LB-40. Agency: CALT. More at: 8219.


Photo Gallery

CZ-2F at LA4CZ-2F at LA4


CZ-2F LRBCZ-2F LRB


CZ-2FCZ-2F


Chinese Manned LVsChinese Manned LVs
Chinese Launch Vehicles for Manned Projects. From left: Tsien Spaceplane Launcher, 1978; Project 921 Launch Vehicle, 1992; CZ-2F, 1999; CZ-2E(A), 2000. Only the last two were put into full scale development.
Credit: © Mark Wade


CZ-2F RolloutCZ-2F Rollout


CZ-2F in VABCZ-2F in VAB


CZ-2F Escape TowerCZ-2F Escape Tower


CZ-2F Rollout BigCZ-2F Rollout Big


CZ-2F on pad FullCZ-2F on pad Full



1999 March 11 - . LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Chinese Man-Rated Launch Vehicle Test Predicted - . Nation: China. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. It was reported on the Internet that the maiden flight of a new version of the CZ-2E designed to carry a manned vehicle would be made by mid-1999..

1999 May 1 - . LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Manned Program Delayed - . Nation: China. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Far eastern newspapers reported an accident at Jiuquan Launch Center late May 1999. It was said that a fuel depot exploded, resulting in casualties and delaying the first manned vehicle launch originally scheduled for October..

1999 June 9 - . LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • CZ-2F Photograph Appears on the Internet - . Nation: China. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou.

    A photograph of the CZ-2F manned spacecraft launch vehicle and its vertical assembly building was posted anonymously on the Internet. It was said to have been taken in May 1998 at the Jiuquan launch site by a contruction contractor. Some believed the photograph to be a phony but events later proved it to be real and a deliberate leak.


1999 August 15 - . LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • China Upgrades Launch Facilities - . Nation: China.

    Tang Xianming, Director of the Xichang Launch Center, confirmed the construction of a new Vertical Assembly Facility at the Jiuquan Launch Center. He also affirmed that China would continue to use the Xichang Launch Center, which would be upgraded with improved data processing and control equipment.


1999 November 19 - . 22:30 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou - . Mass: 7,600 kg (16,700 lb). Nation: China. Agency: CASC. Manufacturer: CALT. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 0.88 days. Decay Date: 1999-11-20 . USAF Sat Cat: 25956 . COSPAR: 1999-061A. Apogee: 315 km (195 mi). Perigee: 195 km (121 mi). Inclination: 42.6000 deg. Period: 89.60 min.

    The unmanned first test flight of a prototype of the Chinese Project 921-1 spacecraft took place 49 days after the planned date of October 1, 1999. Shenzhou separated from its launch vehicle and went into orbit about ten minutes after lift-off. The spacecraft was controlled from the new Beijing Aerospace Directing and Controlling Centre. The spacecraft did not manoeuvre during the flight. The first attempt to return the spacecraft to earth came on orbitt 12, but the retrofire command would not be accepted by the spacecraft's computer. A retry on the next orbit also failed.

    The Yuanwang-3 tracking ship off the coast of Namibia picked up the spacecraft's signal at 18:49 UT, and commanded retro-fire. This time the spacecraft accepted the command, which probably saved the entire program. The spacecraft passed out of range of the tracking ship nine minutes later. Its trajectory arced over Africa, skimmed the coast of the Arabian peninsula, and then over Pakistan, before re-entering over Tibet.

    Following re-entry, the drogue chute deployed at an altitude of 30 km with the capsules soft-landing rockets firing 1.5 m above the ground. The capsule landed at 41 deg N, 105 deg E, (415 km East of its launch pad and 110 km north-west of Wuhai, Inner Mongolia), at November 20 19:41 UT. The spacecraft had completed 14 orbits of the earth in 21 hours and 11 minutes.

    After the flight it was reported that not a single primary spacecraft system had failed, so none of the back-up systems were tested. The touchdown point was only 12 km from the predicted position. The soft landing braking rocket worked well - no damage was found to the capsule structure, heat shield or the seals. The jettisoned heat shield, parachute hatch, and drogue chute were found within 5 km of the landing point. The orbital module, which separated prior to retro-fire, continued in controlled flight until 27 November, when it decayed and reentered the atmosphere. A primary payload returned by Shenzhou were 100 kg of seeds, considered valuable to the Chinese after one day of exposure to the space environment. The Chinese space tracking fleet returned from the Shenzhou mission between 12 December 1999 and 4 January 2000. During their 259-day voyage, the four ships traveled 185,000 km and experienced some heavy seas while tracking and communicating with the Shenzhou for a total of 150 minutes. Additional Details: here....


2001 January 9 - . 17:00 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 2 - . Mass: 7,400 kg (16,300 lb). Nation: China. Agency: CASC. Manufacturer: CALT. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 6.77 days. Decay Date: 2001-01-16 . USAF Sat Cat: 26664 . COSPAR: 2001-001A. Apogee: 345 km (214 mi). Perigee: 330 km (200 mi). Inclination: 42.6000 deg. Period: 91.30 min.

    The second unmanned test flight of the Shenzhou manned spacecraft design carried a monkey, a dog and a rabbit in a test of the spaceship's life support systems. Shenzhou 2 was the first test of an all-up flight model of the spacecraft, with a functioning orbital module. It was also the most ambitious space science laboratory ever launched by China. It carried 64 scientific payloads: 15 in the re-entry module, 12 in the orbital module and 37 on the forward external pallet. These included a micro-gravity crystal growing device; life sciences experiments with 19 species of animals and plants, cosmic ray and particle detectors; and China's first gamma ray burst detectors.

    The launch was originally scheduled for January 5, but the second stage of the launch vehicle was dented by an access platform while being prepared for roll-out in the vehicle assembly building. This caused several days of delay until it was cleared for flight. Shenzhou 2 made three orbit-raising manoeuvres during its flight, reaching a 330 x 345 km orbit by the end of the initial phase of the mission. Ninety minutes before landing the orbital module depressurised, and the spacecraft went briefly out of control. However this was regained after venting of the atmosphere from the module ended. The descent module and service modules separated from the forward orbital module and external pallet normally. After retrofire by the service module, it separated and the descent module landed at 11:22 GMT on January 16 in Inner Mongolia. Lack of post-recovery photographs led to speculation that the recovery may not have been completely successful. The Shenzhou orbital module had its own solar panels and remained operational in orbit, conducting scientific experiments. It was actively controlled for six months, maneuvering in orbit several times (reaching a final orbit of 394 x 405 km). It then was allowed to decay and reentered the atmosphere at 09:05 GMT on August 24, 2001. The reentry point was near 33.1 deg S in latitude and 260.4 deg E in longitude, over the western Pacific Ocean between Easter Island and Chile.


2002 March 25 - . 14:15 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 3 - . Mass: 7,800 kg (17,100 lb). Nation: China. Agency: CAS. Manufacturer: CALT. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 6.78 days. Decay Date: 2002-04-01 . USAF Sat Cat: 27397 . COSPAR: 2002-014A. Apogee: 379 km (235 mi). Perigee: 374 km (232 mi). Inclination: 42.4000 deg. Period: 92.10 min.

    The third unmanned test of the Shenzhou spacecraft was delayed almost three months when a defective connector was found on the booster after roll-out to the pad in January 2002. The vehicle was disassembled, and all suspect connectors were replaced. The stand-down also revealed ten previously undetected defects in the space capsule. The spacecraft, the first all-up flight model with a functioning (but deactivated) launch escape system, was finally launched and placed into an initial 197 x 326 km x 42.4 deg orbit at 1425 UTC. At about 2120 UTC Shenzhou used its own engine to raise its orbit to 332 x 337 km. The capsule included a dummy astronaut instrumented to monitor life support systems. The descent module returned to Earth on April 1 at 0851 UTC, landing in Inner Mongolia. The orbital module remained in orbit to carry out further experiments, finally being deorbited on 12 November 2002. The spacecraft carried 44 scientific payloads, including a medium-resolution imaging radiometer developed by Chinese Academy of Sciences, installed on the instrument pallet atop the orbital module.


2002 December 29 - . 16:49 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 4 - . Mass: 7,794 kg (17,182 lb). Nation: China. Agency: CAS. Manufacturer: CALT. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 6.77 days. Decay Date: 2003-01-05 . USAF Sat Cat: 27630 . COSPAR: 2002-061A. Apogee: 337 km (209 mi). Perigee: 331 km (205 mi). Inclination: 42.4000 deg. Period: 91.20 min.

    Final unmanned test of the Shenzhou spacecraft. First night launch of the CZ-2F was viewed by Party leaders on a very cold but clear night. The spacecraft carried fifty-two science payloads in four main areas: microwave Earth observation, space environment monitoring, microgravity fluid physics, and biological technology research. The spacecraft's reentry capsule was successfully recovered on 5 January 2003 at 1116 UT. The Chinese released the news and photographs of the capsule in the dusk snow only an hour later. The landing site was 40 km from Hohhot (40.51deg N, 111.38 deg E). As in prior missions, the orbital module continued in orbit. Chinese astronauts trained on the actual flight hardware before the launch and it was officially announced that this successful mission set the stage for a first Chinese manned spaceflight in the second half of 2003. Western observors noted that the orbit and ground track allowed launch of a second rendezvous vehicle, an indication of future manned space station missions. Shenzhou 4 carried 52 scientific payloads including a microwave radiometer using a reflector antenna, installed on top of the orbital module.


2003 October 15 - . 01:00 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 5 Orbital Module - . Mass: 1,100 kg (2,400 lb). Nation: China. Agency: SISE. Class: Surveillance. Type: Military surveillance satellite. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou OM. Decay Date: 2004-05-30 . USAF Sat Cat: 28049 . COSPAR: 2003-045G. Apogee: 347 km (215 mi). Perigee: 338 km (210 mi). Inclination: 42.4000 deg. Period: 91.40 min.

    The Shenzhou 5 orbital module was essential an unmanned military reconnaisance satellite. It was never entered by the astronaut during the mission, and was equipped with two high resolution (1.6 m) surveillance cameras. It was expected to operate until at least spring 2004.

  • Shenzhou 5 - . Crew: Yang Liwei. Backup Crew: Zhai Zhigang. Support Crew: Nie Haisheng. Mass: 7,840 kg (17,280 lb). Nation: China. Related Persons: Nie Haisheng, Yang Liwei, Zhai Zhigang. Agency: PLAAF. Manufacturer: CALT. Class: Manned. Type: Manned spacecraft. Flight: Shenzhou 5. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 0.89 days. Decay Date: 2003-10-16 . USAF Sat Cat: 28043 . COSPAR: 2003-045A. Apogee: 336 km (208 mi). Perigee: 332 km (206 mi). Inclination: 42.4192 deg. Period: 91.20 min.

    China's first manned spaceflight began with the lift-off of the CZ-2F booster into the clear blue morning sky. All went according to plan and China's first man in space, Yang Liwei, entered an initial 200 km x 343 km orbit ten minutes after launch. The naval vessels standing buy for rescue in the Sea of Japan were called back to port.

    The highly conservative mission plan was for Yang to remain in the Shenzhou re-entry capsule for the entire 21-hour mission, and not to enter the orbital module. He had two rest periods of three hours each, and was scheduled to eat once or twice meals of what was said to be a superior form of Chinese space food. Frequent communications sessions, including colour television links to the spacecraft, were made possible by China's four tracking ships deployed in the oceans of the world.

    As the spacecraft was in its 21st orbit, the orbital module separated. It would stay in the 343 km orbit for a planned six-month military imaging reconnaissance mission. Retrofire was commanded via a tracking ship in the Atlantic off the coast of Africa. Shenzhou-5 landed only 4.8 km from the aim-point in Inner Mongolia with the parachute being sighted by the ground recovery forces prior to landing. Yang landed after 21 hours 23 minutes aloft.


2005 October 12 - . 01:00 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 6 - . Crew: Fei Junlong, Nie Haisheng. Backup Crew: Jing Haipen, Liu Buoming. Return Crew: Wu Jie, Zhai Zhigang. Mass: 8,040 kg (17,720 lb). Nation: China. Related Persons: Fei Junlong, Jing Haipen, Liu Buoming, Nie Haisheng, Wu Jie, Zhai Zhigang. Agency: SISE. Class: Manned. Type: Manned spacecraft. Flight: Shenzhou 6. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 4.81 days. Decay Date: 2005-10-16 . USAF Sat Cat: 28879 . COSPAR: 2005-040A. Apogee: 338 km (210 mi). Perigee: 331 km (205 mi). Inclination: 42.4000 deg. Period: 91.20 min.

    Moved up from October 13. Second Chinese manned space mission. The two-astronaut crew spent 5 days in space, and worked in the Shenzhou orbital module for the first time. Aside from biomedical experiments, the nature of their work was not divulged, and few images of the interior of the orbital module (with its probable military experiments) were released.


2008 September 25 - . 13:10 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan SLS. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 7 - . Crew: Jing Haipen, Liu Buoming, Zhai Zhigang. Mass: 7,840 kg (17,280 lb). Nation: China. Related Persons: Jing Haipen, Liu Buoming, Zhai Zhigang. Agency: SISE. Class: Manned. Type: Manned spacecraft. Flight: Shenzhou 7. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 2.85 days. Decay Date: 2008-09-28 . USAF Sat Cat: 33386 . COSPAR: 2008-047A. Apogee: 336 km (208 mi). Perigee: 329 km (204 mi). Inclination: 42.4000 deg. Period: 91.20 min.

    Third Chinese manned space mission. The crew consisted of Zhai Zhigang, backup astronaut for China's first manned space mission; and Liu Buoming and Jing Haipeng, backups for the second mission. The astronauts demonstrated the capability of the Shenzhou spacecraft to carry its full complement of three crew for the first time. Zhai, wearing a Chinese-developed Feitian space suit, emerged from the orbital module of the Shenzhou and became China's first astronaut to conduct a spacewalk. Liu, wearing a proven Russian Orlan spacesuit, remained in the depressurized orbital module, ready to assist Zhai in an emergency. A subsatellite, weighing 40 kg, was released after the EVA, and relayed back images of Shenzhou 7 from close range to a distance of several kilometers. The crew returned safely to earth in a pinpoint landing in Outer Mongolia, carried live on television. The orbital module remained in space, conducting space network experiments with the subsatellite.

  • BX-1 - . Mass: 40 kg (88 lb). Nation: China. Agency: SISE. Class: Technology. Type: Navigation technology satellite. Flight: Shenzhou 7. Spacecraft Bus: Ban Xing. Spacecraft: Ban Xing. Decay Date: 2009-10-29 . USAF Sat Cat: 33392 . COSPAR: 2008-047G. Apogee: 331 km (205 mi). Perigee: 321 km (199 mi). Inclination: 42.4000 deg. Period: 91.00 min. BanXing (companion satellite) subsatellite released by Shenzhou 7. If maneuvered away and back to the Shenzhou orbital module after the mission..

2011 October 31 - . 21:58 GMT - . Launch Site: Jiuquan. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 8 - . Mass: 7,800 kg (17,100 lb). Nation: China. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 16.57 days. Decay Date: 2011-11-17 . USAF Sat Cat: 37859 . COSPAR: 2011-063A. Apogee: 338 km (210 mi). Perigee: 328 km (203 mi). Inclination: 42.8000 deg. Period: 91.20 min.

    Unmanned test of Shenzhou manned spacecraft. Automatically docked with Tiangong 1 space laboratory at 17:28 GMT on 2 November. Undocked on 14 November at 11:27 GMT, backed off 140 m, and conducted a second successful automatic docking at 11:53 GMT. Undocked the final time at 10:30 GMT on 16 November and landed in China at 11:32 GMT on 17 November.


2012 June 16 - . 10:37 GMT - . Launch Site: Jiuquan. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 9 - . Mass: 7,800 kg (17,100 lb). Nation: China. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 12.64 days. Decay Date: 2012-06-29 . USAF Sat Cat: 38461 . COSPAR: 2012-032A. Apogee: 355 km (220 mi). Perigee: 334 km (207 mi). Inclination: 42.8000 deg. Period: 91.40 min.

2013 June 11 - . 09:38 GMT - . Launch Site: Jiuquan. LV Family: CZ. Launch Vehicle: Chang Zheng 2F.
  • Shenzhou 10 - . Crew: Nie Haisheng, Wang Yaping, Zhang Xiaoguan. Mass: 7,800 kg (17,100 lb). Nation: China. Class: Manned. Type: Manned spacecraft. Spacecraft Bus: Shenzhou. Spacecraft: Shenzhou. Duration: 14.60 days. Decay Date: 2013-06-25 . USAF Sat Cat: 39179 . COSPAR: 2013-029A. Apogee: 337 km (209 mi). Perigee: 333 km (206 mi). Inclination: 42.7800 deg. Period: 91.23 min.

    Docked with the Tiangong-1 spacelab on June 13 at 05:11 GMT. On June 23 the crew carried out a redocking exercise. They undocked Shenzhou 10 from Tiangong at 00:26 GMT, backed away from the station, and redocked with it at 02:00 GMT. On June 24 the crew undocked for the final time, made a flyaround of the Tiangong station, and then prepared to return to Earth. The deorbit burn was at about 23:23 GMT Jun3 25. The capsule landed in China at 00:07 GMT June 26, at 42.33N 111.36E.
