DF-5



DF-5
Development of the the DF-5 began in 1964. The goal was an ICBM capable of reaching the United States. Although deployed in very limited numbers as an ICBM, this rocket became the basis for an entire family of space launch vehicles and the foundation of the Chinese space program.

The missile was designed from the beginning to include China's first full inertial navigation guidance package. On January 4, 1966, Tsien proposed development of a countermeasures package for the DF-5 to evade American anti-ballistic missile systems. This was to included electronic jammers and spoofers and balloon decoys. American investigators would claim, beginning in the 1990's, that the CZ-5 incorporated Titan 2 missile technology. Flight tests began in 1971 but the missile did not enter service until 1981, following a series of two recoverable-warhead tests.

Standard warhead: 3,000 kg (6,600 lb). Maximum range: 12,020 km (7,460 mi). Number Standard Warheads: 1. Warhead yield: 3,300 KT. CEP: 0.44 km (0.27 mi). Boost Propulsion: Storable liquid rocket, N2O4/UDMH. Initial Operational Capability: 1981. Total Number Built: 4.

AKA: Dong Feng 5; CSS-4.
Status: Active.
Gross mass: 181,000 kg (399,000 lb).
Payload: 3,000 kg (6,600 lb).
Height: 32.61 m (106.98 ft).
Diameter: 3.35 m (10.99 ft).
Span: 3.35 m (10.99 ft).
Thrust: 2,500.00 kN (562,000 lbf).
Apogee: 1,000 km (600 mi).
First Launch: 1971.09.10.
Last Launch: 1981.12.07.
Number: 10 .

More... - Chronology...


Associated Countries
See also
  • CZ China's first ICBM, the DF-5, first flew in 1971. It was a two-stage storable-propellant rocket in the same class as the American Titan, the Russian R-36, or the European Ariane. The DF-5 spawned a long series of Long March ("Chang Zheng") CZ-2, CZ-3, and CZ-4 launch vehicles. These used cryogenic engines for upper stages and liquid-propellant strap-on motors to create a family of 12 Long-March rocket configurations capable of placing up to 9,200 kg into orbit. In 2000 China began development of a new generation of expendable launch vehicles using non-toxic, high-performance propellants with supposedly lower operating costs. However these encountered development delays, and it seemed the reliable Long March series of rockets would continue in operational use for nearly fifty years before being replaced. More...
  • missile Guided self-propelled military weapon (as opposed to rocket, an unguided self-propelled weapon). More...

Associated Manufacturers and Agencies
  • CALT Chinese manufacturer of rockets, spacecraft, and rocket engines. China Academy of Launch Vehicle Technology, Beijing, China. More...

Associated Launch Sites
  • Jiuquan China's first launch center, also known as Shuang Cheng Tzu. Jiuquan Satellite Launch Centre, situated at 100 degrees East, 41 degrees North, is located in the Jiuquan Region, Gansu province, north-western China. It was China's first ballistic missile and satellite launch centre. More...

Associated Stages
  • FB-1-1 N2O4/UDMH propellant rocket stage. Loaded/empty mass 150,400/10,000 kg. Thrust 3,000.00 kN. Vacuum specific impulse 289 seconds. More...
  • FB-1-2 N2O4/UDMH propellant rocket stage. Loaded/empty mass 38,300/3,500 kg. Thrust 761.90 kN. Vacuum specific impulse 295 seconds. More...

DF-5 Chronology


1971 September 10 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Research and Development Suborbital Flight.

1973 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Vehicle: DF-5.
  • - . Nation: China. Apogee: 1,000 km (600 mi).

1979 January 7 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Other sources say launch was from Taiyuan..

1979 July 15 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Other sources say launch was from Taiyuan..

1979 August 21 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Other sources say launch was from Taiyuan on 2 August..

1979 September 4 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Other sources say launch was from Taiyuan..

1979 November 26 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Other sources say launch was from Taiyuan on 15 October..

1980 February 15 - . Launch Site: Taiyuan. LV Family: CZ. Launch Vehicle: DF-5.
  • Last DF-5 partial range test. - . Nation: China. Program: Long March. Summary: Other sources do not list this test..

1980 May 18 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • Test mission - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi).

1980 May 21 - . 02:00 GMT - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • Test mission - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi).

1981 December 7 - . Launch Site: Jiuquan. Launch Complex: Jiuquan LA2B. Launch Pad: LA2B?. LV Family: CZ. Launch Vehicle: DF-5.
  • - . Nation: China. Agency: PRC. Apogee: 1,000 km (600 mi). Summary: Other sources say launch was from Taiyuan..
